ANTI DRONE PRODUCT’s TECHNICAL DESCRIPTION

Product Name:Fixed Directional Jammer

Place of Manufacturing (City & Country): Hangzhou, China

Specifications:

1.Operating Frequency Bands: 400MHz, 800MHz, 900MHz, 1.2GHz, 1.4GHz, 1.5GHz, 2.4GHz, 5.1GHz, 5.4GHz, 5.8GHz

2.Interference Modes: Disengage mode and forced landing mode.

3.Interference Range: 0-3km (may vary depending on the environment and UAV model).

4.Interference Response Time: <5s.

5.Gimbal Rotation Angle: Horizontal 360° Vertical 0 - 60°

6.Gimbal Rotation Speed: Horizontal 0.02° to 20s, Pitch 0.02° to 10°/s.

7.Communication Interface: RJ45/RS485.

8.Total Power Consumption: <1000W.

9.Heat dissipation: Natural cooling + fan.

10.Operating Temperature: -40C to +60C.

11.Weight:<30kg..

12.Protection Level: IP66.

13.Power Supply: AC220V+44V.

14.Continuous Operating Time: Supports outdoor 7x24-hour use.
